Model |
Gentier 48R |
Gentier 48E |
|
Throughput |
1-48
|
1-48
|
|
Fluorescence Channels |
2 |
4 |
|
Fluorescence Scanning Time |
2s
|
2s
|
|
Dye Compatibility |
· Channel 1: FAM, SYBR Green I , SYTO 9, Eva Green, LC Green · Channel 2: HEX, VIC, TET, JOE |
· Channel 1: FAM, SYBR Green I , SYTO 9, Eva Green, LC Green · Channel 2: HEX, VIC, TET, JOE · Channel 3: Channel 3: ROX, Texas Red · Channel 4: Cy5 |
|
Optical System |
||
|
Light Source |
High-brightness, long life and maintenance-free LED light source |
High-brightness, long life and maintenance-free LED light source |
|
Detector |
Photodiodes (PDs)
|
Photodiodes (PDs)
|
|
Excitation Range |
CH1: 470nm CH2:523nm CH3:570nm CH4:638nm |
CH1: 470nm CH2:523nm CH3:570nm CH4:638nm |
|
Detection Range |
CH1:525nm CH2:564nm CH3:610nm CH4:685nm |
CH1:525nm CH2:564nm CH3:610nm CH4:685nm
|
|
Fluorescence Dynamic Range |
Adjustable |
Adjustable |
|
Sample Dynamic Range |
From 101 to 1010copies
|
From 101 to 1010copies
|
|
Thermal Black |
||
|
Heating Method |
Peltier |
Peltier |
|
Heating Rate |
≥8.0 ℃/s ℃ |
≥8.0 ℃/s ℃ |
|
Cooling Rate |
≥6.2 ℃/s
|
≥6.2 ℃/s
|
|
Temperature Accuracy |
≤0.1 ℃ |
≤0.1 ℃ |
|
Gradient Range |
1℃-40 ℃
|
1℃-40 ℃
|
|
Gradient Block |
8 row |
8 row |
|
Special Temperature Protocol |
Thermal gradients PCR, long PCR, Touch Down PCR
|
Thermal gradients PCR, long PCR, Touch Down PCR
|
|
Sample Testing Linearity and Repeatability |
Linear correlation: /r/ ≥ 0.999 |
Linear correlation: /r/ ≥ 0.999 |
|
Software Functions |
||
|
Control Modes |
Model1: 7 inch touch screen |
Model1: 7 inch touch screen |
|
Power Failure Protection |
Automatically start running experiments after power supply, no need to wait PC software |
Automatically start running experiments after power supply, no need to wait PC software |
|
Data Storage and Transmission |
Upload and download through USB disk. 1000 results can be stored in machine |
Upload and download through USB disk. 1000 results can be stored in machine |
|
Reporting Function |
Templates reserved; customized experiment report |
Templates reserved; customized experiment report |
|
Key Applications |
Relative quantification, absolute quantification, melting curve analysis ,SNP analysis |
Relative quantification, absolute quantification, melting curve analysis ,SNP analysis |
|
Others |
||
|
Operating System for PC |
Win7/Win10/Win11
|
Win7/Win10/Win11
|
|
Power Supply and Power Consumption |
AC 100-240V,S0-60HZ; 600VA |
AC 100-240V,S0-60HZ; 600VA |
|
Weight |
11 Kg (net)
|
11 Kg (net)
|
|
Instrument Dimension |
260*400*260mm (W*L*H) |
260*400*260mm (W*L*H) |
|
Suitable Consumables |
0.2mL clear non-skirt 48-WELL plates, 8>tube strips, single tubes, etc.
|
0.2mL clear non-skirt 48-WELL plates, 8>tube strips, single tubes, etc.
|
|
Certificate |
IVDR CE |
IVDR CE |
