Performance:

Throughput: Photometric test: 1000 tests/hour; ISE: 600 tests/hour (optional)

System functions: Continuous standby for 7*24 hours, emergency test, automatic dilution, automatic retest, automatic sleep and wakeup 1 ~ 4 reagents, dual-wavelength test, customized reaction time setting (1 ~ 60 minutes)

Scope of test: Clinical chemistry and electrolytes (optional)

Type of sample: Serum, plasma, urine, whole blood, cerebrospinal fluid

Analytical method: One-point endpoint method, dual-point endpoint method, kinetic method (reaction speed method), fixed time method (two-point speed method) and ISE indirect measurement method

Calibration method: Linear calibration: K factor method and linear method (including dual-point linear method and multi-pointlinear method) Non-linear calibration: transect method, broken line method, exponential method, logarithmic method, 3P parameter method, 4P parameter method and 5P parameter method

Maximum number of items for simultaneous analysis: 98 dual-reagent biochemistry items + 3 electrolyte items

Sample System:

Sample position: 325 sample positions: including 300 track sample positions (including 30 emergency positions), available for bar code scanning; 25 disc emergency positions, available for bar code scanning (optional), 2 ~ 8℃ refrigeration function

Sample volume: 1.0 ~ 35.0µL, progressively increased by 0.1µL

Sample probe: Level sensing, volume tracking, anti-collision protection, sample clot detection (optional), automatic maintenance and cleaning, with a cross-contamination rate of lower than 0.08%

Sample tube: Available for mixed placement of centrifugal cup, micro sample cup, glass blood sampling test tube, plastic blood sampling test tube and other types of samples

Reagent System:

Reagent tray: All 200 reagent positions are available for bar code scanning (optional) and support reagent bottles with volumes of 75mL, 45mL and 25mL

Reagent volume: R1: 80 ~ 300µL; R2: 10 ~ 300µL; progressively increased by 0.5µ

Reagent probe: Level sensing, volume tracking, anti-collision protection and automatic maintenance and cleaning

Refrigeration of reagent: 2 ~ 8℃

Optical System:

Light source: Halogen lamp

Spectral method: Flat-filed concave grating and diode array, with post spectro detection technology

Wavelength: 16 wavelength：340nm, 380nm, 410nm, 450nm, 478nm, 505nm, 546nm, 578nm, 600nm, 630nm, 660nm, 700nm, 750nm, 780nm, 800nm, 850nm

Measurement range of absorbance: -0.5 ~ 3.5Abs

Mixing System:

Mixing arm: Independent mixing arm

 Mixing technology: Available for automatic frequency conversion

Washing System:

Washing steps: Automatic washing within 8 steps

Washing solution: Acid and alkaline washing solution

Working Conditions:

Weight: 533Kg

Size: 1770mm (length) ×990mm (width) ×1238mm (height)

Power supply: ~ 230 V ±10%, 50 Hz/60 Hz ± 1 Hz

Power: 2500VA

Water consumption: Less than 45 liter/hour
